WZ Series Zero Gravity Mixer

paddledryer

zero gravity mixer



1.Principle of the machine

This series machine takes a strong and high effective mixing as its features the two mixing axles rotate reversely at an identical revolution in the horizontal drum body. The paddles,specially distributed on the axle ensure that the material move radically, circulatingly, and axially, so as to from a compound motion, and in an extremely short time, the material is mixed evenly.



2.Features:

The equipment can run in an enciosure, with highprecision, high speed, low energy consumption.
Pheumatical, electrical and manual discharging metod.
The atomizing device can be distributed on the cylinder cover to realize the solid-liquid mixing.

3.Applicable materials

It is suitable for the drying and mixing of the following materials:chemicals, detergent, fertilizer, feedstuff, feedstuff additive wheat flour, milk power, perfume, micro ingredient, coffee, gourmet power, salt, plastic and all kinds of pulp, power material.

4.Technical parameter

spec WZ-0.05 WZ-0.1
WZ-0.3
WZ-0.5 WZ-1 WZ-2 WZ-3 WZ-4 WZ-6
mixed amount/batch kg 24-30 40-60
120-180
200-300 400-600 800-1200 1200-1800 1600-2400 2400-3600
power kw 2.2 3
4-5.5
5.5-7.5 7.5-11 11-15 18.5-22 22-30 30-37
weight kg 250 360
750
880 2100 2740 3800 5100 6200
